clean room Technology is a system to create your operating setting clean or avoid contamination , Its employed in producing , storage, packing , as well as of pharmaceutical product , research, Animal Housing Labs & Vivarium's, Cannabis Cultivation Rooms, CMM Rooms, Controlled & important Environments, E-Cigarette producing, Environmental Enclosures, Fab Labs, robe Rooms, GMP Rooms, IV Rooms, Laboratories, Machine Enclosures, science Labs, electronics producing, Nano Technology, Oil Mist Enclosures, Packaging Rooms, Paint System Enclosures, Pharmaceutical Packaging, Powder Coating Enclosures, Printing Rooms, Storage Rooms, USP 797 Clean Rooms, USP 800 Clean Rooms and part semiconductor engineering applications with an occasional level of environmental pollutants appreciate mud, mobile microbes, aerosol particles, and chemical vapors.
We are established manufacturer, provider and bourgeois during this room business .Experienced: professional Trunkey Clean rooms, standard Clean rooms style, producing, installation and certification since 2000. We tend to had engineered quite one hundred clean rooms.
Quality construction: We manufacture all our components in house. Installation is done by our factory team.
ISO 14644-1 Cleanroom Standards
| Class | maximum particles/m3 | FED STD 209E equivalent |
|||||
| >=0.1 µm | >=0.2 µm | >=0.3 µm | >=0.5 µm | >=1 µm | >=5 µm | ||
| ISO 1 | 10 | 2 | |||||
| ISO 2 | 100 | 24 | 10 | 4 | |||
| ISO 3 | 1,000 | 237 | 102 | 35 | 8 | Class 1 | |
| ISO 4 | 10,000 | 2,370 | 1,020 | 352 | 83 | Class 10 | |
| ISO 5 | 100,000 | 23,700 | 10,200 | 3,520 | 832 | 29 | Class 100 |
| ISO 6 | 1,000,000 | 237,000 | 102,000 | 35,200 | 8,320 | 293 | Class 1,000 |
| ISO 7 | 352,000 | 83,200 | 2,930 | Class 10,000 | |||
| ISO 8 | 3,520,000 | 832,000 | 29,300 | Class 100,000 | |||
| ISO 9 | 35,200,000 | 8,320,000 | 293,000 | Room Air | |||
| maximum particles/m3 | |||||
| Class | >=0.5 µm | >=1 µm | >=5 µm | >=10 µm | >=25 µm |
| Class 1 | 3,000 |
0 |
0 |
0 |
|
| Class 2 | 300,000 |
2,000 |
30 |
||
| Class 3 | 1,000,000 |
20,000 |
4,000 |
300 |
|
| Class 4 | 20,000 |
40,000 |
4,000 |
||
